High temperature kiln pad burning aluminia ceramic plate
Description:
Alumina ceramic plate is used in high temperature sintering
furnace,Play the role of mat burning. So the high temperature
resistance and insulation properties of alumina can better protect
customers' zinc oxide products.
Principal characteristic of High temperature kiln pad burning aluminia ceramic plate:
1. Thermal characteristics: heat resistance and thermal
conductivity
2. Mechanical properties: high strength and hardness
3. Other features: high electrical insulation, corrosion
resistance, high biocompatibility.
Application of High temperature kiln pad burning aluminia ceramic plate:
Ultrafine grinding equipment, fine chemical industry, electronic
paste, semiconductor, new energy, nano new materials, medical
instruments, precision casting, structural ceramics, refractory
materials, electronic communications, sensitive ceramics,
petrochemical industry, aerospace, machinery manufacturing, optical
fiber connector, battery materials and other high-precision end
fields.
Technical Parameters:
| Material | >92% Al2O3 | >95% Al2O3 | >99% Al2O3 | >99.7% Al2O3 | >99.9% Al2O3 |
| Color | white | white | white | white,off-white | off-white |
| Density | 3.45 | 3.5 | 3.75 | 3.9 | 3.92 |
| flexure strength | 340 | 300 | 330 | 390 | 390 |
| compressive strength | 3600 | 3400 | 2800 | 3900 | 3900 |
| elasticity modulus | 350 | 350 | 370 | 390 | 390 |
| impact resistance | 4.2 | 4 | 4.4 | 5.2 | 5.5 |
| Weibull Modulus | 11 | 10 | 10 | 12 | 12 |
| Vickers hardness | 1700 | 1800 | 1800 | 2000 | 2000 |
| coefficient of thermal expansion | 5.0-8.3 | 5.0-8.3 | 5.1-8.3 | 5.5-8.4 | 5.5-8.5 |
| Thermal conductivit | 18 | 24 | 25 | 28 | 30 |
| Thermal stability | 220 | 250 | 250 | 280 | 280 |
| maximum service temperature | 1500 | 1600 | 1600 | 1700 | 1700 |
| 20℃volume resistance | >10ˆ14 | >10ˆ14 | >10ˆ14 | >10ˆ15 | >10ˆ15 |
| dielectric strength | 20 | 20 | 20 | 30 | 30 |
| dielectric constant | 10 | 10 | 10 | 10 | 10 |
